@napi-rs/image

Transform and optimize images library.

See Examples (opens in a new tab) for usage.

install size (opens in a new tab) Downloads (opens in a new tab)

Transformer:

This library support encode/decode these formats:

FormatInputOutput
RawPixelsRGBA 8 bits pixels
JPEGBaseline and progressiveBaseline JPEG
PNGAll supported color typesSame as decoding
BMPRgb8, Rgba8, Gray8, GrayA8
ICO
TIFFBaseline(no fax support) + LZW + PackBitsRgb8, Rgba8, Gray8
WebPNo
AVIFNo
PNMPBM, PGM, PPM, standard PAM
DDSDXT1, DXT3, DXT5No
TGARgb8, Rgba8, Bgr8, Bgra8, Gray8, GrayA8
OpenEXRRgb32F, Rgba32F (no dwa compression)Rgb32F, Rgba32F (no dwa compression)
farbfeld
SVG

See index.d.ts (opens in a new tab) for API reference.

New from Constructor

import { Transformer } from '@napi-rs/image'

const transformer = new Transformer(input)

New from RGBA RawPixels

import { Transformer } from '@napi-rs/image'
import { decode } from 'blurhash'

// Uint8ClampedArray
const pixels = decode('LEHV6nWB2yk8pyo0adR*.7kCMdnj', 32, 32)
const transformer = Transformer.fromRgbaPixels(pixels, 32, 32)

Render the SVG to Other Image Format

import { promises as fs } from 'fs'

import { Transformer } from '@napi-rs/image'

const SVG = await fs.readFile('input-debian.svg')

writeFileSync(
  'output-debian.jpeg',
  await Transformer.fromSvg(
    SVG,
    /** Support CSS3 color, e.g. rgba(255, 255, 255, .8) */
    'rgba(238, 235, 230, .9)',
)

Metadata

metadata(withExif?: boolean | undefined | null, signal?: AbortSignal | undefined | null): Promise<Metadata>

export interface Metadata {
  width: number
  height: number
  exif?: Record<string, string> | undefined | null
  orientation?: number | undefined | null
  format: string
  colorType: JsColorType
}

export const enum JsColorType {
  /** Pixel is 8-bit luminance */
  L8 = 0,
  /** Pixel is 8-bit luminance with an alpha channel */
  La8 = 1,
  /** Pixel contains 8-bit R, G and B channels */
  Rgb8 = 2,
  /** Pixel is 8-bit RGB with an alpha channel */
  Rgba8 = 3,
  /** Pixel is 16-bit luminance */
  L16 = 4,
  /** Pixel is 16-bit luminance with an alpha channel */
  La16 = 5,
  /** Pixel is 16-bit RGB */
  Rgb16 = 6,
  /** Pixel is 16-bit RGBA */
  Rgba16 = 7,
  /** Pixel is 32-bit float RGB */
  Rgb32F = 8,
  /** Pixel is 32-bit float RGBA */
  Rgba32F = 9
}

Example:

import { promises as fs } from 'fs'

import { Transformer } from '@napi-rs/image'

const WITH_EXIF_JPG = await fs.readFile('with-exif.jpg')

const decoder = new Transformer(WITH_EXIF_JPG)
const metadata = await decoder.metadata(true)

The metadata will be

{
  colorType: 2,
  exif: {
    Orientation: 'Unknown (5)',
    'Resolution Unit': 'in',
    'This image has an Exif SubIFD': '90',
    'X Resolution': '72 pixels per in',
    'Y Resolution': '72 pixels per in',
  },
  format: 'jpeg',
  height: 450,
  orientation: 5,
  width: 600,
}

Transform Image format

import { promises as fs } from 'fs'

import { Transformer } from '@napi-rs/image'

const PNG = await fs.readFile('./un-optimized.png')

const webp = await new Transformer(PNG).webp()

await fs.writeFile('optimized.webp)

webp

The quality factor quality_factor ranges from 0 to 100 and controls the loss and quality during compression.
The value 0 corresponds to low quality and small output sizes, whereas 100 is the highest quality and largest output size.
> https://developers.google.com/speed/webp/docs/api#simple_encoding_api (opens in a new tab)
Default is 90

webp(qualityFactor: number, signal?: AbortSignal | undefined | null): Promise<Buffer>
webpSync(qualityFactor: number): Buffer
/// Encode lossless webp image
webpLossless(signal?: AbortSignal | undefined | null): Promise<Buffer>
webpLosslessSync(): Buffer

AVIF

Config:

export interface AvifConfig {
  /** 0-100 scale 100 is lossless */
  quality?: number | undefined | null
  /** 0-100 scale */
  alphaQuality?: number | undefined | null
  /** rav1e preset 1 (slow) 10 (fast but crappy), default is 4 */
  speed?: number | undefined | null
  /** How many threads should be used (0 = match core count) */
  threads?: number | undefined | null
  /** set to '4:2:0' to use chroma subsampling, default '4:4:4' */
  chromaSubsampling?: ChromaSubsampling | undefined | null
}

/**
 * https://en.wikipedia.org/wiki/Chroma_subsampling#Types_of_sampling_and_subsampling
 * https://developer.mozilla.org/en-US/docs/Web/Media/Formats/Video_concepts
 */
export const enum ChromaSubsampling {
  /**
   * Each of the three Y'CbCr components has the same sample rate, thus there is no chroma subsampling. This scheme is sometimes used in high-end film scanners and cinematic post-production.
   * Note that "4:4:4" may instead be wrongly referring to R'G'B' color space, which implicitly also does not have any chroma subsampling (except in JPEG R'G'B' can be subsampled).
   * Formats such as HDCAM SR can record 4:4:4 R'G'B' over dual-link HD-SDI.
   */
  Yuv444 = 0,
  /**
   * The two chroma components are sampled at half the horizontal sample rate of luma: the horizontal chroma resolution is halved. This reduces the bandwidth of an uncompressed video signal by one-third.
   * Many high-end digital video formats and interfaces use this scheme:
   * - [AVC-Intra 100](https://en.wikipedia.org/wiki/AVC-Intra)
   * - [Digital Betacam](https://en.wikipedia.org/wiki/Betacam#Digital_Betacam)
   * - [Betacam SX](https://en.wikipedia.org/wiki/Betacam#Betacam_SX)
   * - [DVCPRO50](https://en.wikipedia.org/wiki/DV#DVCPRO) and [DVCPRO HD](https://en.wikipedia.org/wiki/DV#DVCPRO_HD)
   * - [Digital-S](https://en.wikipedia.org/wiki/Digital-S)
   * - [CCIR 601](https://en.wikipedia.org/wiki/Rec._601) / [Serial Digital Interface](https://en.wikipedia.org/wiki/Serial_digital_interface) / [D1](https://en.wikipedia.org/wiki/D-1_(Sony))
   * - [ProRes (HQ, 422, LT, and Proxy)](https://en.wikipedia.org/wiki/Apple_ProRes)
   * - [XDCAM HD422](https://en.wikipedia.org/wiki/XDCAM)
   * - [Canon MXF HD422](https://en.wikipedia.org/wiki/Canon_XF-300)
   */
  Yuv422 = 1,
  /**
   * n 4:2:0, the horizontal sampling is doubled compared to 4:1:1,
   * but as the **Cb** and **Cr** channels are only sampled on each alternate line in this scheme, the vertical resolution is halved.
   * The data rate is thus the same.
   * This fits reasonably well with the PAL color encoding system, since this has only half the vertical chrominance resolution of [NTSC](https://en.wikipedia.org/wiki/NTSC).
   * It would also fit extremely well with the [SECAM](https://en.wikipedia.org/wiki/SECAM) color encoding system,
   * since like that format, 4:2:0 only stores and transmits one color channel per line (the other channel being recovered from the previous line).
   * However, little equipment has actually been produced that outputs a SECAM analogue video signal.
   * In general, SECAM territories either have to use a PAL-capable display or a [transcoder](https://en.wikipedia.org/wiki/Transcoding) to convert the PAL signal to SECAM for display.
   */
  Yuv420 = 2,
  /**
   * What if the chroma subsampling model is 4:0:0?
   * That says to use every pixel of luma data, but that each row has 0 chroma samples applied to it. The resulting image, then, is comprised solely of the luminance data—a greyscale image.
   */
  Yuv400 = 3,
}
avif(options?: AvifConfig | undefined | null, signal?: AbortSignal | undefined | null): Promise<Buffer>
avifSync(options?: AvifConfig | undefined | null): Buffer

PNG

PngEncodeOptions:

export interface PngEncodeOptions {
  /** Default is `CompressionType::Default` */
  compressionType?: CompressionType | undefined | null
  /** Default is `FilterType::NoFilter` */
  filterType?: FilterType | undefined | null
}
export const enum CompressionType {
  /** Default compression level */
  Default = 0,
  /** Fast, minimal compression */
  Fast = 1,
  /** High compression level */
  Best = 2,
  /** Huffman coding compression */
  Huffman = 3,
  /** Run-length encoding compression */
  Rle = 4,
}
export const enum FilterType {
  /**
   * No processing done, best used for low bit depth greyscale or data with a
   * low color count
   */
  NoFilter = 0,
  /** Filters based on previous pixel in the same scanline */
  Sub = 1,
  /** Filters based on the scanline above */
  Up = 2,
  /** Filters based on the average of left and right neighbor pixels */
  Avg = 3,
  /** Algorithm that takes into account the left, upper left, and above pixels */
  Paeth = 4,
  /**
   * Uses a heuristic to select one of the preceding filters for each
   * scanline rather than one filter for the entire image
   */
  Adaptive = 5,
}
png(options?: PngEncodeOptions | undefined | null, signal?: AbortSignal | undefined | null): Promise<Buffer>
pngSync(options?: PngEncodeOptions | undefined | null): Buffer

JPEG

/** default `quality` is 90 */
jpeg(quality?: number | undefined | null, signal?: AbortSignal | undefined | null): Promise<Buffer>
/** default `quality` is 90 */
jpegSync(quality?: number | undefined | null): Buffer

BMP

bmp(signal?: AbortSignal | undefined | null): Promise<Buffer>
bmpSync(): Buffer

ICO

ico(signal?: AbortSignal | undefined | null): Promise<Buffer>
icoSync(): Buffer

TIFF

tiff(signal?: AbortSignal | undefined | null): Promise<Buffer>
tiffSync(): Buffer

PNM

pnm(signal?: AbortSignal | undefined | null): Promise<Buffer>
pnmSync(): Buffer

TGA

tga(signal?: AbortSignal | undefined | null): Promise<Buffer>
tgaSync(): Buffer

Farbfeld

farbfeld(signal?: AbortSignal | undefined | null): Promise<Buffer>
farbfeldSync(): Buffer

Manipulate Image

rotate

Rotate the image with exif orientation, if the input image contains no exif information, this API will have no effect.

/**
 * Rotate with exif orientation
 * If the orientation param is not null,
 * the new orientation value will override the exif orientation value
 */
rotate(): this

Example:

This image has orientation value 5 in exif:


Without rotate:

import { promises as fs } from 'fs'

import { Transformer } from '@napi-rs/image'

const WITH_EXIF_JPG = await fs.readFile('with-exif.jpg')

const imageOutputWithoutRotateWebp = await new Transformer(WITH_EXIF).resize(450 / 2).webp(75)

writeFileSync('output-exif.no-rotate.image.webp', imageOutputWithoutRotateWebp)


With rotate:

import { promises as fs } from 'fs'

import { Transformer } from '@napi-rs/image'

const WITH_EXIF_JPG = await fs.readFile('with-exif.jpg')

const imageOutputWebp = await new Transformer(WITH_EXIF)
  .rotate()
  .resize(450 / 2)
  .webp(75)

console.timeEnd('@napi-rs/image webp')

writeFileSync('output-exif.image.webp', imageOutputWebp)


grayscale

/**
 * Return a grayscale version of this image.
 * Returns `Luma` images in most cases. However, for `f32` images,
 * this will return a greyscale `Rgb/Rgba` image instead.
 */
grayscale(): this
ImageOutput

invert

Invert the colors of this image.

invert(): this
ImageOutput

resize

/**
 * Resize this image using the specified filter algorithm.
 * The image is scaled to the maximum possible size that fits
 * within the bounds specified by `width` and `height`.
 */
resize(width: number, height?: number | undefined | null, filterType?: ResizeFilterType | undefined | null): this

export const enum ResizeFilterType {
  /** Nearest Neighbor */
  Nearest = 0,
  /** Linear Filter */
  Triangle = 1,
  /** Cubic Filter */
  CatmullRom = 2,
  /** Gaussian Filter */
  Gaussian = 3,
  /** Lanczos with window 3 */
  Lanczos3 = 4
}

ResizeFilterType:

To test the different sampling filters on a real example, you can find two examples called scaledown (opens in a new tab) and scaleup (opens in a new tab) in the examples directory of the crate source code.

Here is a 3.58 MiB test image (opens in a new tab) that has been scaled down to 300x225 px:

Nearest
Nearest Neighbor
Triangle
Linear: Triangle
CatmullRom
Cubic: Catmull-Rom
Gaussian
Gaussian
Lanczos3
Lanczos with window 3

Speed

Time required to create each of the examples above, tested on an Intel i7-4770 CPU with Rust 1.37 in release mode:


Filter TypeTime Cost
Nearest31 ms
Triangle414ms
CatmullRom817ms
Gaussian1180 ms
Lanczos31170 ms

blur

Performs a Gaussian blur on this image.
sigma` is a measure of how much to blur by.

blur(sigma: number): this

blur(10)

ImageOutput

unsharpen

Performs an unsharpen mask on this image.
sigma is the amount to blur the image by.
> threshold is a control of how much to sharpen.
See Digital_unsharp_masking (opens in a new tab)

unsharpen(sigma: number, threshold: number): this

unsharpen(10, 10)

ImageOutput

filter3x3

Filters this image with the specified 3x3 kernel. Error will thrown if the kernel length is not 9.

filter3x3(kernel: Array<number>): this

https://en.wikipedia.org/wiki/Kernel_(image_processing)#Details (opens in a new tab)
Sharpen:

filter3x3([0, -1, 0, -1, 5, -1, 0, -1, 0])

ImageOutput

adjustContrast

Adjust the contrast of this image.
contrast is the amount to adjust the contrast by.
Negative values decrease the contrast and positive values increase the contrast.

adjustContrast(contrast: number): this

adjustContrast(50)

ImageOutput

brighten

Brighten the pixels of this image.
value is the amount to brighten each pixel by.
Negative values decrease the brightness and positive values increase it.

brighten(brightness: number): this

brighten(30)

ImageOutput

huerotate

Hue rotate the supplied image.
> value is the degrees to rotate each pixel by. 0 and 360 do nothing, the rest rotates by the given degree value. just like the css webkit filter hue-rotate(180)

huerotate(hue: number): this

huerotate(90)

ImageOutput

crop

Crop a cut-out of this image delimited by the bounding rectangle.

crop(270, 40, 500, 500)

ImageOutput

Optimize PNG

Lossless compression

Lossless optimize PNG powered by oxipng (opens in a new tab).

PNGLosslessOptions

export interface PNGLosslessOptions {
  /**
   * Attempt to fix errors when decoding the input file rather than returning an Err.
   * Default: `false`
   */
  fixErrors?: boolean | undefined | null
  /**
   * Write to output even if there was no improvement in compression.
   * Default: `false`
   */
  force?: boolean | undefined | null
  /** Which filters to try on the file (0-5) */
  filter?: Array<number> | undefined | null
  /**
   * Whether to attempt bit depth reduction
   * Default: `true`
   */
  bitDepthReduction?: boolean | undefined | null
  /**
   * Whether to attempt color type reduction
   * Default: `true`
   */
  colorTypeReduction?: boolean | undefined | null
  /**
   * Whether to attempt palette reduction
   * Default: `true`
   */
  paletteReduction?: boolean | undefined | null
  /**
   * Whether to attempt grayscale reduction
   * Default: `true`
   */
  grayscaleReduction?: boolean | undefined | null
  /**
   * Whether to perform IDAT recoding
   * If any type of reduction is performed, IDAT recoding will be performed regardless of this setting
   * Default: `true`
   */
  idatRecoding?: boolean | undefined | null
  /** Whether to remove ***All non-critical headers*** on PNG */
  strip?: boolean | undefined | null
  /** Whether to use heuristics to pick the best filter and compression */
  useHeuristics?: boolean | undefined | null
}
export function losslessCompressPng(
  input: Buffer,
  options?: PNGLosslessOptions | undefined | null,
  signal?: AbortSignal | undefined | null,
): Promise<Buffer>
export function losslessCompressPngSync(input: Buffer, options?: PNGLosslessOptions | undefined | null): Buffer

Lossy compression

Powered by pngquant (opens in a new tab), converts RGBA images to palette-based 8-bit indexed images, including alpha component.

PngQuantOptions:

export interface PngQuantOptions {
  /** default is 70 */
  minQuality?: number | undefined | null
  /** default is 99 */
  maxQuality?: number | undefined | null
  /**
   * 1- 10
   * Faster speeds generate images of lower quality, but may be useful for real-time generation of images.
   * default: 5
   */
  speed?: number | undefined | null
  /**
   * Number of least significant bits to ignore.
   * Useful for generating palettes for VGA, 15-bit textures, or other retro platforms.
   */
  posterization?: number | undefined | null
}
export function pngQuantize(
  input: Buffer,
  options?: PngQuantOptions | undefined | null,
  signal?: AbortSignal | undefined | null,
): Promise<Buffer>
export function pngQuantizeSync(input: Buffer, options?: PngQuantOptions | undefined | null): Buffer

Optimize JPEG

Lossy and Lossless JPEG compression powered by mozjpeg (opens in a new tab).

JpegCompressOptions:

export interface JpegCompressOptions {
  /** Output quality, default is 100 (lossless) */
  quality?: number | undefined | null
  /**
   * If true, it will use MozJPEG’s scan optimization. Makes progressive image files smaller.
   * Default is `true`
   */
  optimizeScans?: boolean | undefined | null
}
export function compressJpeg(
  input: Buffer,
  options?: JpegCompressOptions | undefined | null,
  signal?: AbortSignal | undefined | null,
): Promise<Buffer>
export function compressJpegSync(input: Buffer, options?: JpegCompressOptions | undefined | null): Buffer

Credits

See Credits
